HEDS-5605#G06
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Sensors, Transducers / Encoders
Description
Optical Encoder Rotary Incremental Round with Slot Straight Digital Through Hole PC Pins 360CPR
PDF
/
Buying Options
Total Price: USD $66.09
Unit Price: USD $66.0877
≥1 USD $66.0877
≥10 USD $64.0224
≥100 USD $61.9571
≥500 USD $59.8918
≥1000 USD $53.6959
Inventory: 354
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Pulses per Revolution 360
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 2
Operating Supply Voltage 5V
Output Type Quadrature (Incremental)
Actuator Type 1/4 Open Center
Termination Style Terminal Pins
Number of Functions 1
Orientation Vertical
Min Operating Temperature -40°C
Max Operating Temperature 70°C
ECCN Code EAR99
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series HEDS
Published 2014
Physical
Number of Pins 5
Package / Case Metal
Mounting Type Chassis Mount, Motors
Mount Chassis Mount
Supply Chain
Factory Lead Time 12 Weeks
