HEDS-5600#H06
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Sensors, Transducers / Encoders
Description
Optical Encoder Rotary Incremental Round with Slot Straight Digital Through Hole PC Pins 400CPR
PDF
/
Inventory: 9919
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Pulses per Revolution 400
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 2
Operating Supply Voltage 5V
Output Type Quadrature (Incremental)
Actuator Type 1/4 Open Center
Termination Style Terminal Pins
Number of Functions 1
Orientation Vertical
HTS Code 8543.70.96.50
Min Operating Temperature -40°C
Max Operating Temperature 70°C
ECCN Code EAR99
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series HEDS
Published 2014
Physical
Number of Pins 10
Package / Case Metal
Mounting Type Chassis Mount, Motors
Mount Chassis Mount
Supply Chain
Factory Lead Time 12 Weeks
