HEDS-5540#A02
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Sensors, Transducers / Encoders
Description
BROADCOM LIMITED HEDS-5540#A02 ENCODER, 3CHANNEL, 500CPR
PDF
/
Buying Options
Total Price: USD $56.46
Unit Price: USD $56.4608
≥1 USD $56.4608
≥10 USD $52.18752
≥100 USD $48.83032
≥500 USD $44.8624
≥1000 USD $41.963328
≥3000 USD $39.67436
Inventory: 83
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Pulses per Revolution 500
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 3
Output Type Quadrature with Index (Incremental)
Actuator Type 3mm Open Center
Termination Style Terminal Pins
Current Rating 5mA
Number of Functions 1
Orientation Vertical
Voltage - Supply 5V
Min Operating Temperature -40°C
Max Operating Temperature 100°C
ECCN Code EAR99
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series HEDS
Published 2012
Physical
Number of Pins 5
Package / Case Metal
Mounting Type Chassis Mount, Motors
Mount Chassis Mount, Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 12 Weeks
Alternative Model
