HEDS-5500#I13
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
ROTARY ENCODER OPTICAL 512PPR
PDF
/
Buying Options
Total Price: USD $313.32
Unit Price: USD $313.3195
≥1 USD $313.3195
Inventory: 307
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Chassis Mount, Motors
Surface Mount NO
Mounting Feature THROUGH HOLE MOUNT
Technical
Published 2014
Series HEDS
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
HTS Code 8543.70.96.50
Voltage - Supply 5V
Orientation Vertical
Number of Functions 1
Termination Style Terminal Pins
Operating Temperature (Max) 100°C
Actuator Type 8mm Open Center
Operating Temperature (Min) -40°C
Output Type Quadrature (Incremental)
Configuration SINGLE, 2 CHANNELS
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 512
Compliance
RoHS Status ROHS3 Compliant
