HEDS-5500#G12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
Encoders 2 Channel 360 CPR 6mm Metal CW
PDF
/
Inventory: 6836
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Pulses per Revolution 360
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Configuration SINGLE, 2 CHANNELS
Output Type Quadrature (Incremental)
Operating Temperature (Min) -40°C
Actuator Type 6mm Open Center
Operating Temperature (Max) 100°C
Termination Style Terminal Pins
Reach Compliance Code compliant
Number of Functions 1
Orientation Vertical
Voltage - Supply 5V
HTS Code 8543.70.96.50
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series HEDS
Published 2009
Physical
Mounting Feature THROUGH HOLE MOUNT
Surface Mount NO
Mounting Type Chassis Mount, Motors
