HEDS-5500#C11
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Sensors, Transducers / Encoders
Description
Optical Encoder Rotary Incremental Round with Slot Straight Digital Through Hole PC Pins 100CPR
PDF
/
Buying Options
Total Price: USD $48.08
Unit Price: USD $48.077214
≥1 USD $48.077214
≥10 USD $45.355863
≥100 USD $42.788553
≥500 USD $40.366559
≥1000 USD $38.081653
Inventory: 9418
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Pulses per Revolution 100
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 2
Operating Supply Voltage 5V
Output Type Quadrature (Incremental)
Actuator Type 4mm Open Center
Termination Style Terminal Pins
Number of Functions 1
Orientation Vertical
Min Operating Temperature -40°C
Max Operating Temperature 70°C
ECCN Code EAR99
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series HEDS
Published 2014
Physical
Number of Pins 5
Package / Case Metal
Mounting Type Chassis Mount, Motors
Mount Chassis Mount
Supply Chain
Factory Lead Time 12 Weeks
