HEDS-5500#C02
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Sensors, Transducers / Encoders
Description
Optical Encoder Rotary Incremental Round with Slot Straight Digital Through Hole PC Pins 100CPR
PDF
/
Inventory: 958
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Pulses per Revolution 100
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 2
Operating Supply Voltage 5V
Output Type Quadrature (Incremental)
Actuator Type 3mm Open Center
Termination Style Terminal Pins
Number of Functions 1
Orientation Vertical
Min Operating Temperature -40°C
Max Operating Temperature 70°C
ECCN Code EAR99
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series HEDS
Published 2014
Physical
Number of Pins 5
Package / Case Metal
Mounting Type Chassis Mount, Motors
Mount Chassis Mount, Screw
Contact Plating Gold
Supply Chain
Factory Lead Time 12 Weeks
