HEDR-55L2-BY09
RoHS
/
Package Module
Category Sensors, Transducers / Encoders
Description
BROADCOM LIMITED HEDR-55L2-BY09 HOUSED ENCODER, 3-CH, 3600CPR, 8MM HUB
PDF
/
Inventory: 9976
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Technical
Pulses per Revolution 3600
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 3
Operating Supply Voltage 5V
Output Type Quadrature with Index (Incremental)
Actuator Type 8mm Open Center
Termination Style Terminal Pins
Current Rating 38mA
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Termination Cable
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series HEDR
Published 2012
Packaging Bulk
Physical
Number of Pins 10
Package / Case Module
Mounting Type Chassis Mount, Motors
Mount Chassis Mount
Supply Chain
Factory Lead Time 8 Weeks
