HEDR-5421-EP111
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Sensors, Transducers / Encoders
Description
BROADCOM LIMITED HEDR-5421-EP111 Incremental Rotary Encoder, Housed, 2 Channel Quadrature Output
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Nominal Supply Voltage (DC) 5V
Pulses per Revolution 200
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 2
Output Type Quadrature (Incremental)
Actuator Type 4mm Open Center
Termination Style Terminal Pins
Number of Functions 1
Orientation Right Angle
Min Operating Temperature -10°C
Max Operating Temperature 85°C
ECCN Code EAR99
Termination Cable
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series HEDR
Published 2012
Physical
Number of Pins 5
Package / Case Module
Mounting Type Chassis Mount, Motors
Mount Chassis Mount
Supply Chain
Factory Lead Time 20 Weeks
