HEDL-5645#A13
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
Optical Encoder Rotary Incremental Straight Digital Square Wave Cable
PDF
/
Inventory: 4825
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Nominal Supply Voltage (DC) 5V
Pulses per Revolution 500
Detent No
Encoder Type Optical
Optoelectronic Device Type OPTOELECTRONIC DEVICE
Number of Channels 3
Operating Supply Voltage 5V
Output Type Quadrature with Index (Incremental)
Actuator Type 8mm Open Center
Termination Style Cable with Connector
Current Rating 5mA
Number of Functions 1
Orientation Vertical
HTS Code 8541.40.80.00
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Termination Cable
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series HEDL
Published 2008
Physical
Number of Pins 10
Mounting Type Chassis Mount, Motors
Mount Chassis Mount
Supply Chain
Factory Lead Time 12 Weeks
