HEDB-9040-B11
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
Encoders 3 Channel 1000 CPR 4mm Carbon Wheel
PDF
/
Inventory: 5513
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Chassis Mount, Motors
Technical
Published 2010
Series HEDB-9040
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
HTS Code 8543.70.96.50
Voltage - Supply 5V
Number of Functions 1
Reach Compliance Code compliant
Termination Style Terminal Pins
Operating Temperature (Max) 100°C
Actuator Type 4mm Open Center
Operating Temperature (Min) -40°C
Output Type Quadrature with Index (Incremental)
Configuration SINGLE, 3 CHANNELS
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 1000
Compliance
RoHS Status RoHS Compliant
