AEDT-9140-E00

Broadcom Limited
RoHS
RoHS RoHS compliant
Package Module
Category Sensors, Transducers / Encoders
Description Optical Encoder Rotary Incremental Straight Digital Screw Mount 200CPR
PDF
/
Inventory: 2553
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Pulses per Revolution 200
Detent No
Encoder Type Optical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 3
Output Type Quadrature with Index (Incremental)
Actuator Type Codewheel Not Included
Termination Style Terminal Pins
Number of Functions 1
Voltage - Supply 5V
Min Operating Temperature -40°C
Max Operating Temperature 115°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AEDT-9140
Packaging Bulk

Physical

Number of Pins 5
Package / Case Module
Mounting Type Chassis Mount
Mount Chassis Mount, Screw

Supply Chain

Factory Lead Time 12 Weeks
