AEDT-9140-A00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
AEDT-9140 Terminal Pins Quadrature with Index (Incremental) 500 Optical Encoder 5V 115C
PDF
/
Inventory: 7202
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Chassis Mount
Technical
Published 2009
Series AEDT-9140
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
HTS Code 8543.70.96.50
Voltage - Supply 5V
Number of Functions 1
Reach Compliance Code compliant
Termination Style Terminal Pins
Operating Temperature (Max) 115°C
Actuator Type Codewheel Not Included
Operating Temperature (Min) -40°C
Output Type Quadrature with Index (Incremental)
Configuration SINGLE, 3 CHANNELS
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 500
Compliance
RoHS Status RoHS Compliant
