AEDS-9650-P10

Broadcom Limited
RoHS
RoHS RoHS compliant
Package /
Category Sensors, Transducers / Encoders
Description Optical Encoder Linear Incremental Straight Digital Bracket Mount PC Pins
PDF
/
Inventory: 8183
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Pulses per Revolution 150 LPI
Detent No
Encoder Type Optical
Optoelectronic Device Type LINEAR POSITION ENCODER
Configuration SINGLE, 2 CHANNELS
Output Type Quadrature (Incremental)
Actuator Type Codestrip Not Included
Operating Temperature (Max) 70°C
Termination Style Terminal Pins
Reach Compliance Code compliant
Number of Functions 1
Orientation Vertical
Voltage - Supply 3.3VDC
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series AEDS-965x
Published 2006

Physical

Mounting Feature THROUGH HOLE MOUNT
Surface Mount NO
Mounting Type Chassis Mount
