AEDS-9340-U00

Broadcom Limited
RoHS
RoHS RoHS compliant
Package /
Category Sensors, Transducers / Encoders
Description Encoders 6 Channel 2048CPR Z11 Encoder
PDF
/
Inventory: 3616
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Chassis Mount

Technical

Series AEDS-9340
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Supply 5V
Number of Functions 1
Termination Style Terminal Pins
Operating Temperature (Max) 85°C
Actuator Type Codewheel Not Included
Operating Temperature (Min) -10°C
Output Type Quadrature with Index (Incremental)
Configuration SINGLE, 3 CHANNELS
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 2048

Compliance

RoHS Status RoHS Compliant
