AEDB-9340-T13C
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Sensors, Transducers / Encoders
Description
Optical Encoder Rotary Incremental Hollow 0.113N.m Straight Digital Square Wave Screw Mount PC Pins 2000CPR
PDF
/
Inventory: 8856
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount, Motors
Package / Case Module
Number of Pins 8
Technical
Packaging Bulk
Published 2016
Series AEDB-9340
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination PC Pins
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -10°C
Number of Functions 1
Termination Style Terminal Pins
Actuator Type 8mm Open Center
Output Type Quadrature with Index (Incremental)
Operating Supply Voltage 5V
Configuration SINGLE, 3 CHANNELS
Number of Channels 6
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 2000
Compliance
RoHS Status ROHS3 Compliant
