AEDB-9140-F04
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
AEDB-9140 Terminal Pins Quadrature with Index (Incremental) 256 Optical Encoder 5V 85C
PDF
/
Inventory: 4579
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Chassis Mount, Motors
Surface Mount NO
Mounting Feature THROUGH HOLE MOUNT
Technical
Series AEDB-9140
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Voltage - Supply 5V
Number of Functions 1
Reach Compliance Code compliant
Termination Style Terminal Pins
Operating Temperature (Max) 85°C
Actuator Type 5/32 Open Center
Operating Temperature (Min) -10°C
Output Type Quadrature with Index (Incremental)
Configuration SINGLE, 3 CHANNELS
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 256
Compliance
RoHS Status RoHS Compliant
