AEDA-3300-TBK
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
Optical Encoder Rotary Incremental Hollow 0.003N.m Straight Digital Square Wave Through Hole PC Pins 7500CPR
PDF
/
Inventory: 3007
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Chassis Mount, Motors
Technical
Published 2012
Series AEDA-3300
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Supply 5V
Orientation Vertical
Number of Functions 1
Reach Compliance Code compliant
Termination Style Terminal Pins
Operating Temperature (Max) 125°C
Actuator Type 2mm Open Center
Operating Temperature (Min) -40°C
Output Type Quadrature with Index (Incremental)
Configuration SINGLE, 3 CHANNELS
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 7500
Compliance
RoHS Status RoHS Compliant
