PEC16-2215F-S0024
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
Mechanical Encoder Rotary Incremental Flat 2.83oz-in Right Angle Gray Digital Square Wave 24PPR Through Hole P
PDF
/
Buying Options
Total Price: USD $1.19
Unit Price: USD $1.188
≥1 USD $1.188
≥10 USD $1.0736
≥100 USD $1.0032
≥500 USD $0.919424
≥1000 USD $0.857648
≥3000 USD $0.807136
Inventory: 2922
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount PCB, Panel, Through Hole
Mounting Type Panel, PCB Through Hole
Number of Pins 3
Technical
Packaging Bulk
Published 2010
Series PEC16
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 70°C
Min Operating Temperature -30°C
Orientation Right Angle
Number of Functions 1
Termination Style PC Pin
Actuator Type 6mm Dia Flatted End
Output Type Quadrature (Incremental)
Operating Supply Voltage 5V
Number of Channels 2
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Mechanical
Detent Yes
Pulses per Revolution 24
Rotational Life (Cycles Min) 100K
Dimensions
Height 17.3mm
Length 23mm
Width 16mm
Compliance
RoHS Status ROHS3 Compliant
