PEC12-2017F-S0024

Bourns Inc.
RoHS
RoHS RoHS compliant
Package /
Category Sensors, Transducers / Encoders
Description Mechanical Encoder Rotary Incremental Flat 2.83oz-in Right Angle Gray Digital Square Wave 24PPR Through Hole P
PDF
/
Inventory: 4923
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount PCB, Through Hole
Mounting Type PCB, Through Hole

Technical

Packaging Bulk
Published 2010
Series PEC12
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 70°C
Min Operating Temperature -30°C
Orientation Right Angle
Number of Functions 1
Termination Style PC Pin
Actuator Type 6mm Dia Flatted End
Output Type Quadrature (Incremental)
Operating Supply Voltage 5V
Number of Channels 2
Optoelectronic Device Type ROTARY POSITION ENCODER
Built in Switch Yes
Encoder Type Mechanical
Detent No
Pulses per Revolution 24
Rotational Life (Cycles Min) 30K

Dimensions

Height 13.2mm
Length 23mm
Width 12.4mm

Compliance

RoHS Status ROHS3 Compliant
