PEC11-4230F-S0012
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
Mechanical Encoder Rotary Incremental Flat 2.7oz-in Straight Gray Digital Square Wave Through Hole PC Pins 12
PDF
/
Inventory: 1499
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 12.5mm
Length 36.5mm
Height 13.2mm
Technical
Rotational Life (Cycles Min) 30K
Pulses per Revolution 12
Detent Yes
Encoder Type Mechanical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 2
Output Type Quadrature (Incremental)
Actuator Type 6mm Dia Flatted End
Termination Style PC Pin
Number of Functions 1
Orientation Vertical
Min Operating Temperature -30°C
Max Operating Temperature 70°C
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series PEC11
Published 2009
Physical
Mounting Type Panel, PCB Through Hole
Mount PCB, Panel, Through Hole
