PEC09-2115K-S0012
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Encoders
Description
ROTARY ENCODER MECHANICAL 12PPR
PDF
/
Inventory: 10000
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 9.7mm
Length 28.3mm
Height 11.4mm
Technical
Rotational Life (Cycles Min) 30K
Pulses per Revolution 12
Detent Yes
Encoder Type Mechanical
Optoelectronic Device Type ROTARY POSITION ENCODER
Number of Channels 2
Output Type Quadrature (Incremental)
Actuator Type 6mm Dia Knurled End
Termination Style PC Pin
Number of Functions 1
Orientation Right Angle
Min Operating Temperature -10°C
Max Operating Temperature 70°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series PEC09
Published 2011
Physical
Mounting Type Panel, PCB Through Hole
Mount PCB, Panel, Through Hole
Supply Chain
Factory Lead Time 20 Weeks
