EM14R1D-M25-L032S
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Sensors, Transducers / Encoders
Description
Optical Encoder Rotary Incremental Flat 1.5oz.in Straight Digital Square Wave Through Hole PC Pins 8CPR
PDF
/
Inventory: 3685
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount PCB, Panel, Through Hole
Mounting Type Panel, PCB Through Hole
Package / Case Axial
Number of Pins 6
Technical
Published 2011
Series EM14
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Terminal Finish Tin (Sn)
Max Operating Temperature 70°C
Min Operating Temperature -40°C
Orientation Vertical
Number of Functions 1
Reach Compliance Code not_compliant
Base Part Number EM14R1D
Termination Style PC Pin
Actuator Type 6mm Dia Flatted End
Output Type Quadrature (Incremental)
Operating Supply Voltage 5V
Number of Channels 2
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent Yes
Pulses per Revolution 32
Rotational Life (Cycles Min) 200K
Compliance
RoHS Status ROHS3 Compliant
