AS5145B-HSST
RoHS
RoHS compliant
RoHS compliantPackage SSOP
Category Sensors, Transducers / Encoders
Description
ROTARY ENCODER MAGNETIC 1024PPR
PDF
/
Buying Options
Total Price: USD $4.83
Unit Price: USD $4.83265
≥1 USD $4.83265
≥10 USD $3.9653
≥100 USD $3.8418
≥500 USD $3.71735
≥1000 USD $3.59385
Inventory: 12675
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Pulses per Revolution 1024
Detent No
Encoder Type Magnetic
Resolution 1.5 B
Operating Supply Current 21mA
Max Output Current 4mA
Output Type Quadrature (Incremental)
Actuator Type External Magnet, Not Included
Termination Style SMD (SMT) Tab
Voltage - Supply 3V~3.6V 4.5V~5.5V
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Physical
Number of Pins 16
Package / Case SSOP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 24 Weeks
