AS5132-HSST
RoHS
RoHS compliant
RoHS compliantPackage SSOP
Category Sensors, Transducers / Encoders
Description
Board Mount Hall Effect / Magnetic Sensors
PDF
/
Buying Options
Total Price: USD $13.42
Unit Price: USD $13.42445
≥1 USD $13.42445
≥10 USD $11.01525
≥100 USD $10.6704
≥500 USD $10.3265
≥1000 USD $9.9826
Inventory: 11102
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mounting Type Surface Mount
Package / Case SSOP
Number of Pins 20
Technical
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination SMD/SMT
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Voltage - Supply 4.4V~5.5V
Termination Style SMD (SMT) Tab
Actuator Type External Magnet, Not Included
Output Type PWM
Operating Supply Voltage 5.5V
Operating Supply Current 15mA
Nominal Supply Current 15mA
Resolution 1.0625 B
Encoder Type Magnetic
Detent No
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
