USBUF02W6
RoHS
RoHS compliant
RoHS compliantPackage 6-TSSOP, SC-88, SOT-363
Category Filters / EMI/RFI Filters (LC, RC Networks)
Description
EMI Filter Noise Suppression 30MHz to 1000MHz Gull Wing SMD Automotive T/R
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.3608
≥1 USD $0.3608
≥10 USD $0.34232
≥100 USD $0.331584
≥500 USD $0.320496
≥1000 USD $0.303952
≥3000 USD $0.254179
Inventory: 32119
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-TSSOP, SC-88, SOT-363
Number of Pins 6
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series USBUF
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance 10%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Termination Gull Wing
ECCN Code EAR99
Type Low Pass
Terminal Finish Matte Tin (Sn) - annealed
Applications USB
Capacitance 47pF
Subcategory Bus Terminators
Technology RC (Pi)
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Depth 2.4mm
Pin Count 6
Power Supplies 3.3V
Number of Channels 2
Test Frequency 30MHz
DC Resistance (DCR) 33Ohm
Differential Output YES
ESD Protection Yes
Attenuation Value -28dB @ 900MHz
Filter Order 2nd
Values R = 22 Ω, C = 47pF
Resistance - Channel (Ω) 22
Number of Signal Lines 2
Dimensions
Height 0.043 1.09mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
