5ASTFD5K3F40I5N
RoHS
RoHS compliant
RoHS compliantPackage 1517-BBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - System On Chip (SoC)
Description
IC SOC CORTEX-A9 800MHZ 1517FBGA
PDF
/
Inventory: 5772
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 40mm
Length 40mm
Height Seated (Max) 2.7mm
Technical
Number of Logic Cells 503500
Primary Attributes FPGA - 462K Logic Elements
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Inputs 528
Architecture MCU, FPGA
Connectivity EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, USB OTG
Clock Frequency 622MHz
Peripherals DMA, POR, WDT
Core Processor Dual ARM? Cortex?-A9 MPCore? with CoreSight?
RAM Size 64KB
Speed 800MHz
Number of I/O MCU - 208, FPGA - 540
Supply Voltage-Min (Vsup) 1.07V
Power Supplies 1.11.2/3.32.5V
Supply Voltage-Max (Vsup) 1.13V
Qualification Status Not Qualified
Number of Outputs 528
JESD-30 Code S-PBGA-B1517
Base Part Number 5ASTFD5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1mm
Supply Voltage 1.1V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Field Programmable Gate Arrays
Terminal Finish TIN SILVER COPPER
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e1
Series Arria V ST
Packaging Tray
Operating Temperature -40°C~100°C TJ
Physical
Surface Mount YES
Package / Case 1517-BBGA, FCBGA
Supply Chain
Factory Lead Time 8 Weeks
