TIBPAL22V10-7CFN
RoHS
RoHS compliant
RoHS compliantPackage 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - PLDs (Programmable Logic Device)
Description
ROHS3Compliant Contains Lead Obsolete Surface Mount Programmable Logic Device (PLD) IC 75C 5V 125MHz 1.182714g
PDF
/
Buying Options
Total Price: USD $15.56
Unit Price: USD $15.559432
≥1 USD $15.559432
≥10 USD $14.678705
≥100 USD $13.847838
≥500 USD $13.063998
≥1000 USD $12.324526
Inventory: 1140
Minimum: 1
-
+
Technical Details
Technical
Turn On Delay Time 7.5 ns
Propagation Delay 7.5 ns
Max Supply Current 210mA
Speed 7.5ns
Nominal Supply Current 210mA
Voltage - Input 5V
Number of I/O 10
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Programmable Type PAL
Operating Supply Voltage 5V
Base Part Number PAL22V10
Frequency 125MHz
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series IMPACT-X? PAL?
Packaging Tube
Number of Macro Cells 10
Max Frequency 80MHz
Number of Gates 500
Access Time 7.5 ns
Physical
Weight 1.182714g
Supplier Device Package 28-PLCC (11.51x11.51)
Number of Pins 28
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
