TIBPAL20L8-15CNT
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - PLDs (Programmable Logic Device)
Description
TTL DUAL COMMERCIAL EXTENDED COMBINATORIAL Programmable Logic Device (PLD) IC 75C 4.75V 50MHz 2.54mm
PDF
/
Buying Options
Total Price: USD $388.61
Unit Price: USD $388.613933
≥1 USD $388.613933
≥10 USD $375.835525
≥25 USD $373.222967
≥50 USD $370.628561
≥100 USD $363.005449
≥500 USD $337.052412
Inventory: 1692
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-DIP (0.300, 7.62mm)
Number of Pins 24
Weight 1.753503g
Technical
Packaging Tube
Series IMPACT-X? PAL?
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Max Operating Temperature 75°C
Min Operating Temperature 0°C
Subcategory Programmable Logic Devices
Technology TTL
Terminal Position DUAL
Supply Voltage 5V
Terminal Pitch 2.54mm
Frequency 50MHz
Base Part Number TIBPAL20L8
Pin Count 24
Number of Outputs 8
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade COMMERCIAL EXTENDED
Programmable Type PAL
Number of Circuits 8
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Number of I/O 6
Nominal Supply Current 180mA
Max Supply Current 180mA
Propagation Delay 12 ns
Turn On Delay Time 15 ns
Output Function COMBINATORIAL
Number of Dedicated Inputs 14
Number of Product Terms 64
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
