ATF16V8C-7JU image
Favorite
ATF16V8C-7JU image
Favorite

ATF16V8C-7JU

Microchip Technology
RoHS
RoHS RoHS compliant
Package 20-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - PLDs (Programmable Logic Device)
Description IC PLD 8MC 7.5NS 20PLCC
PDF
/
Buying Options
Total Price: USD $40.27
Unit Price: USD $40.2724
≥1 USD $40.2724
≥10 USD $33.04385
≥100 USD $32.0112
≥500 USD $30.97855
≥1000 USD $29.9459
Inventory: 1376
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-LCC (J-Lead)
Number of Pins 20

Technical

Packaging Tube
Published 1997
Series 16V8
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 20
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Supply Voltage 5V
Terminal Pitch 1.27mm
Frequency 125MHz
Base Part Number ATF16V8C
Number of Outputs 8
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade INDUSTRIAL
Programmable Type EE PLD
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Number of I/O 8
Nominal Supply Current 130mA
Max Supply Current 130mA
Propagation Delay 7.5 ns
Turn On Delay Time 7.5 ns
Access Time 7 ns
Architecture PAL-TYPE
Number of Gates 150
Output Function MACROCELL
Number of Macro Cells 8
Number of Dedicated Inputs 7
Number of Product Terms 64

Dimensions

Height Seated (Max) 4.572mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
