ATF16V8B-10JC
RoHS
/
Package 20-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - PLDs (Programmable Logic Device)
Description
2001 Non-RoHS Compliant Contains Lead Obsolete Programmable Logic Device (PLD) IC 70C 5V 83MHz 722.005655mg
PDF
/
Buying Options
Total Price: USD $1.29
Unit Price: USD $1.2901
≥1 USD $1.2901
≥10 USD $1.05925
≥100 USD $1.026
≥500 USD $0.99275
≥1000 USD $0.9595
Inventory: 21003
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Number of Macro Cells 8
Max Frequency 74MHz
Access Time 10 ns
Turn On Delay Time 10 ns
Propagation Delay 10 ns
Speed 10ns
Voltage - Input 5V
Number of I/O 8
Operating Supply Current 55mA
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Programmable Type EE PLD
Operating Supply Voltage 5V
Base Part Number ATF16V8B
Frequency 83MHz
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Series 16V8
Published 2001
Packaging Tube
Physical
Weight 722.005655mg
Supplier Device Package 20-PLCC (9x9)
Number of Pins 20
Package / Case 20-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
