OMAP3525EZCBCA
RoHS
/
Package 515-VFBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
Processors - Application Specialized Applications Processor
PDF
/
Inventory: 7640
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 weeks ago)
Physical
Package / Case 515-VFBGA, FCBGA
Surface Mount YES
Number of Pins 515
Technical
Operating Temperature -40°C~105°C TJ
Series OMAP-35xx
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 3
Number of Terminations 515
Terminal Finish TIN SILVER COPPER
Subcategory Graphics Processors
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Supply Voltage 1V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number OMAP3525
Pin Count 515
Qualification Status Not Qualified
Supply Voltage-Min (Vsup) 0.985V
Speed 600MHz
uPs/uCs/Peripheral ICs Type MICROPROCESSOR, RISC
Core Processor ARM? Cortex?-A8
Boundary Scan YES
Low Power Mode YES
Format FLOATING POINT
Integrated Cache YES
Voltage - I/O 1.8V 3.0V
Number of UART Channels 3
Number of Cores/Bus Width 1 Core 32-Bit
Graphics Acceleration Yes
RAM Controllers LPDDR
USB USB 1.x (3), USB 2.0 (1)
Additional Interfaces HDQ/1-Wire, I2C, McBSP, McSPI, MMC/SD/SDIO, UART
Co-Processors/DSP Signal Processing; C64x+, Multimedia; NEON? SIMD
Display & Interface Controllers LCD
Dimensions
Height 950μm
Length 14mm
Width 14mm
Thickness 630μm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
