OMAP3503DCUS
RoHS
RoHS compliant
RoHS compliantPackage 423-LFBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
FLOATING POINT DIGITAL SIGNAL PROCESSOR OTHER USB 1.x (3) USB 2.0 (1) BALL IC Microprocessor 0C~90C TJ 16mm 1.35V 288kB
PDF
/
Buying Options
Total Price: USD $44.69
Unit Price: USD $44.68515
≥1 USD $44.68515
≥10 USD $36.6643
≥100 USD $35.5186
≥500 USD $34.3729
≥1000 USD $33.2272
Inventory: 2006
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Length 16mm
Height Seated (Max) 1.4mm
Technical
Display & Interface Controllers LCD
Internal Bus Architecture SINGLE
Barrel Shifter NO
Co-Processors/DSP Multimedia; NEON? SIMD
Additional Interfaces HDQ/1-Wire, I2C, McBSP, McSPI, MMC/SD/SDIO, UART
USB USB 1.x (3), USB 2.0 (1)
RAM Controllers LPDDR
Graphics Acceleration No
Number of Cores/Bus Width 1 Core 32-Bit
Number of UART Channels 3
Voltage - I/O 1.8V 3.0V
Format FLOATING POINT
Low Power Mode YES
Boundary Scan YES
Core Architecture ARM
Address Bus Width 26
Number of Timers/Counters 12
Data Bus Width 32b
Core Processor ARM? Cortex?-A8
Number of Bits 32
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
Memory Type L2 Cache, ROM, SRAM
RAM Size 64kB
Memory Size 288kB
Min Supply Voltage 985mV
Max Supply Voltage 1.35V
Interface I2C, MMC, SDIO, UART, USB
Voltage 1.35V
Pin Count 423
Base Part Number OMAP3503
Frequency 600MHz
Terminal Pitch 0.8mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Graphics Processors
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 423
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e1
Series OMAP-35xx
Packaging Tray
Operating Temperature 0°C~90°C TJ
Physical
Number of Pins 423
Package / Case 423-LFBGA, FCBGA
Mount Surface Mount
