AM5748ABZXEA
RoHS
RoHS compliant
RoHS compliantPackage 760-LFBGA
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
FIXED POINT MICROPROCESSOR RISC USB 2.0 (2) USB 3.0 (2) BALL IC Microprocessor -40C~105C TJ 23mm 1.11V 38.4MHz
PDF
/
Buying Options
Total Price: USD $68.45
Unit Price: USD $68.4464
≥1 USD $68.4464
Inventory: 71
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Package / Case 760-LFBGA
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TJ
Series Sitara?
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 760
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Supply Voltage 1.15V
Terminal Pitch 0.8mm
Base Part Number AM5748
JESD-30 Code S-PBGA-B760
Supply Voltage-Max (Vsup) 1.2V
Supply Voltage-Min (Vsup) 1.11V
Speed 1.5GHz
uPs/uCs/Peripheral ICs Type MICROPROCESSOR, RISC
Core Processor ARM? Cortex?-A15
Clock Frequency 38.4MHz
Address Bus Width 16
Boundary Scan YES
Low Power Mode YES
External Data Bus Width 32
Format FIXED POINT
Integrated Cache YES
Voltage - I/O 1.35V 1.5V 1.8V 3.3V
Ethernet GbE (2)
Number of Cores/Bus Width 1 Core 32-Bit
Graphics Acceleration Yes
RAM Controllers DDR3, DDR3L
USB USB 2.0 (2), USB 3.0 (2)
Additional Interfaces CAN, HDQ/1-Wire, I2C, McASP, MMC/SD/SDIO, QSPI, SPI, SD/SDIO, UART
Co-Processors/DSP ARM? Cortex?-M4, C66x
Security Features ARM TZ, Boot Security, Cryptography, Secure JTAG, Secure RTC
Display & Interface Controllers HDMI, LCD, Video
SATA SATA 3Gbps (1)
Dimensions
Height Seated (Max) 1.63mm
Length 23mm
Compliance
RoHS Status ROHS3 Compliant
