AM5706BCBDJ
RoHS
RoHS compliant
RoHS compliantPackage 538-LFBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
FIXED POINT MICROPROCESSOR RISC USB 2.0 (2) USB 3.0 (2) BALL IC Microprocessor 0C~90C TJ 17mm 1.11V 38.4MHz
PDF
/
Buying Options
Total Price: USD $41.71
Unit Price: USD $41.707966
≥1 USD $41.707966
≥200 USD $16.141028
≥500 USD $16.141028
≥1000 USD $15.293632
Inventory: 1097
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Package / Case 538-LFBGA, FCBGA
Surface Mount YES
Technical
Operating Temperature 0°C~90°C TJ
Series Sitara?
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 538
ECCN Code 5A992C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Supply Voltage 1.15V
Terminal Pitch 0.65mm
Base Part Number AM5706
JESD-30 Code S-PBGA-B538
Supply Voltage-Max (Vsup) 1.2V
Supply Voltage-Min (Vsup) 1.11V
Speed 667MHz
uPs/uCs/Peripheral ICs Type MICROPROCESSOR, RISC
Core Processor ARM? Cortex?-A15
Clock Frequency 38.4MHz
Address Bus Width 16
Boundary Scan YES
Low Power Mode YES
External Data Bus Width 32
Format FIXED POINT
Integrated Cache YES
Voltage - I/O 1.35V 1.5V 1.8V 3.3V
Ethernet 10/100/1000Mbps (2)
Number of Cores/Bus Width 1 Core 32-Bit
Graphics Acceleration Yes
RAM Controllers DDR3, DDR3L
USB USB 2.0 (2), USB 3.0 (2)
Additional Interfaces CAN, HDQ/1-Wire, I2C, McASP, MMC/SD/SDIO, QSPI, SPI, SD/SDIO, UART
Co-Processors/DSP ARM? Cortex?-M4, C66x
Display & Interface Controllers HDMI, Video
Dimensions
Height Seated (Max) 1.298mm
Length 17mm
Compliance
RoHS Status ROHS3 Compliant
