AM1806EZCE4
RoHS
RoHS compliant
RoHS compliantPackage 361-LFBGA
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
Microprocessors - MPU Sitara Processor
PDF
/
Inventory: 4087
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 890μm
Width 13mm
Length 13mm
Height 1.3mm
Technical
Display & Interface Controllers LCD
Number of Cores 1
Co-Processors/DSP System Control; CP15
Additional Interfaces I2C, McASP, McBSP, SPI, MMC/SD, UART
USB USB 2.0 + PHY (1)
RAM Controllers LPDDR, DDR2
Graphics Acceleration No
Number of Cores/Bus Width 1 Core 32-Bit
Number of UART Channels 3
Voltage - I/O 1.8V 3.3V
Integrated Cache YES
Format FIXED POINT
Low Power Mode YES
Boundary Scan YES
Core Architecture ARM
Data Bus Width 32b
Bit Size 32
Core Processor ARM926EJ-S
uPs/uCs/Peripheral ICs Type MICROPROCESSOR, RISC
RAM Size 8kB
Memory Size 64kB
Interface I2C, SPI, UART, USB
Base Part Number AM1806
Frequency 456MHz
Terminal Pitch 0.65mm
Supply Voltage 1.3V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 361
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Series Sitara?
Packaging Tray
Operating Temperature 0°C~90°C TJ
Physical
Number of Pins 361
Package / Case 361-LFBGA
Mount Surface Mount
Contact Plating Copper, Silver, Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
