AM1707BZKBD4
RoHS
RoHS compliant
RoHS compliantPackage 256-BGA
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
FIXED POINT USB 1.1 + PHY (1) USB 2.0 + PHY (1) BALL Surface Mount IC Microprocessor -40C~90C TJ 17mm 1.35V 16kB
PDF
/
Buying Options
Total Price: USD $13.14
Unit Price: USD $13.142246
≥1 USD $13.142246
≥10 USD $12.398343
≥100 USD $11.696555
≥500 USD $11.034485
≥1000 USD $10.409889
Inventory: 1656
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Length 17mm
Height Seated (Max) 2.05mm
Technical
Display & Interface Controllers LCD
Co-Processors/DSP System Control; CP15
Additional Interfaces I2C, McASP, SPI, MMC/SD, UART
USB USB 1.1 + PHY (1), USB 2.0 + PHY (1)
RAM Controllers SDRAM
Graphics Acceleration No
Number of Cores/Bus Width 1 Core 32-Bit
Ethernet 10/100Mbps (1)
Number of UART Channels 3
Voltage - I/O 1.8V 3.3V
Integrated Cache YES
Format FIXED POINT
Low Power Mode YES
Boundary Scan YES
Core Architecture RISC
Address Bus Width 16
Data Bus Width 32b
Bit Size 32
Core Processor ARM926EJ-S
RAM Size 8kB
Memory Size 16kB
Min Supply Voltage 1.25V
Max Supply Voltage 1.35V
Interface I2C, SPI, UART
Voltage 1.35V
Operating Supply Voltage 1.3V
Pin Count 256
Base Part Number AM1707
Frequency 456MHz
Terminal Pitch 0.5mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Microprocessors
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 256
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e1
Series Sitara?
Packaging Tray
Operating Temperature -40°C~90°C TJ
Physical
Number of Pins 256
Package / Case 256-BGA
Mount Surface Mount
