ST72T121J2B6

STMicroelectronics
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
PDF
/
Inventory: 6430
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case PDIP
Surface Mount NO

Technical

JESD-609 Code e0
Number of Terminations 42
Terminal Finish TIN LEAD
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Microcontrollers
Technology HCMOS
Terminal Position DUAL
Terminal Form THROUGH-HOLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 5V
Terminal Pitch 1.778mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 42
Qualification Status Not Qualified
Power Supplies 5V
Temperature Grade INDUSTRIAL
Interface SCI, SPI
Max Supply Voltage 5.5V
Min Supply Voltage 3.5V
Memory Size 8kB
Number of I/O 32
RAM Size 512B
Memory Type EPROM, OTP
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Bit Size 8
Frequency (Max) 8MHz
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
Number of Programmable I/O 32
RAM (bytes) 384
ROM Programmability OTPROM

Dimensions

Height Seated (Max) 5.08mm
Length 36.83mm

Compliance

RoHS Status RoHS Compliant
