MPC8377EVRALGA
RoHS
RoHS compliant
RoHS compliantPackage 689-BBGA Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
PowerPC e300c4s Microprocessor IC MPC83xx 1 Core, 32-Bit 667MHz 689-TEPBGA II (31x31)
PDF
/
Buying Options
Total Price: USD $153.13
Unit Price: USD $153.1343
≥1 USD $153.1343
≥10 USD $148.02995
≥100 USD $132.7169
Inventory: 829
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Package / Case 689-BBGA Exposed Pad
Surface Mount YES
Technical
Operating Temperature 0°C~125°C TA
Packaging Tray
Published 2002
Series MPC83xx
JESD-609 Code e2
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 689
ECCN Code 5A002.A.1
Terminal Finish TIN COPPER/TIN SILVER
HTS Code 8542.31.00.01
Subcategory Microprocessors
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Supply Voltage 1V
Terminal Pitch 1mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MPC8377
JESD-30 Code S-PBGA-B689
SATA SATA 3Gbps (2)
Security Features Cryptography, Random Number Generator
Co-Processors/DSP Security; SEC 3.0
Additional Interfaces DUART, I2C, MMC/SD, PCI, SPI
USB USB 2.0 + PHY (1)
RAM Controllers DDR, DDR2
Graphics Acceleration No
Number of Cores/Bus Width 1 Core 32-Bit
Ethernet 10/100/1000Mbps (2)
Voltage - I/O 1.8V 2.5V 3.3V
Integrated Cache YES
Format FLOATING POINT
External Data Bus Width 32
Low Power Mode YES
Boundary Scan YES
Address Bus Width 32
Bit Size 32
Clock Frequency 66.66MHz
Core Processor PowerPC e300c4s
uPs/uCs/Peripheral ICs Type MICROPROCESSOR
Speed 667MHz
Supply Voltage-Min (Vsup) 0.95V
Power Supplies 11.8/2.52.5/3.3V
Supply Voltage-Max (Vsup) 1.05V
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 31mm
Height Seated (Max) 2.46mm
