AT91SAM9XE256-QU
RoHS
RoHS compliant
RoHS compliantPackage 208-BFQFP
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
Internal USB 2.0 (3) Surface Mount Brown-out Detect/Reset DMA POR PWM WDT IC Microprocessor 85C 28mm 3.6V 32kB
PDF
/
Inventory: 6119
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 28mm
Length 28mm
Height 3.6mm
Technical
Number of Ethernet Channels 1
Number of SPI Channels 2
Display & Interface Controllers LCD, Touchscreen
Number of I2C Channels 2
Additional Interfaces EBI/EMI, I2C, ISI, MMC/SD/SDIO, SPI, SSC, UART/USART
USB USB 2.0 (3)
RAM Controllers SDRAM, SRAM
Graphics Acceleration No
Number of Cores/Bus Width 1 Core 32-Bit
Ethernet 10/100Mbps
Number of ADC Channels 4
Number of UART Channels 1
Voltage - I/O 1.8V 2.5V 3.3V
Number of Programmable I/O 96
Max Frequency 180MHz
Core Architecture ARM
Number of Timers/Counters 6
Data Bus Width 32b
Watchdog Timer Yes
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor ARM926EJ-S
Memory Type FLASH, ROM
RAM Size 32kB
Speed 180MHz
Number of I/O 96
Oscillator Type Internal
Memory Size 32kB
Min Supply Voltage 1.65V
Max Supply Voltage 3.6V
Interface 2-Wire, EBI/EMI, Ethernet, I2C, I2S, MMC, SPI, UART, USART, USB
Operating Supply Voltage 3.3V
Base Part Number AT91SAM9XE256
Frequency 180MHz
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series SAM9XE
Published 2010
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Supplier Device Package 208-PQFP (28x28)
Number of Pins 208
Package / Case 208-BFQFP
Mount Surface Mount
