TN80L186EB13
RoHS
/
Package LCC
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
MPU 80186 Processor 16-Bit 13MHz 84-Pin PLCC
PDF
/
Inventory: 9906
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case LCC
Number of Pins 80
Technical
Packaging Bulk
JESD-609 Code e0
Number of Terminations 84
ECCN Code 3A991.A.2
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature DRAM REFRESH CONTROLLER; 3 PROGRAMMABLE TIMERS; EMULATION HARDWARE
HTS Code 8542.31.00.01
Subcategory Microprocessors
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 1.27mm
Frequency 13MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 84
JESD-30 Code S-PQCC-J84
Qualification Status Not Qualified
Temperature Grade INDUSTRIAL
Voltage 3V
Max Supply Voltage 5V
Min Supply Voltage 2.7V
uPs/uCs/Peripheral ICs Type MICROPROCESSOR
Supply Current-Max 73mA
Bit Size 16
Access Time 13 μs
Address Bus Width 20
Boundary Scan NO
Low Power Mode YES
External Data Bus Width 16
Format FIXED POINT
Integrated Cache NO
RAM (words) 0
Number of Serial I/Os 2
Number of External Interrupts 6
Dimensions
Height Seated (Max) 4.83mm
Length 29.3116mm
Width 29.3116mm
Compliance
RoHS Status Non-RoHS Compliant
