TN80C188XL12
RoHS
/
Package LCC
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
IC MPU I186 12MHZ 68PLCC
PDF
/
Inventory: 7067
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case LCC
Technical
JESD-609 Code e0
Number of Terminations 68
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature DRAM REFRESH CONTROLLER; 3 PROGRAMMABLE TIMERS
HTS Code 8542.31.00.01
Subcategory Microprocessors
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 5V
Terminal Pitch 1.27mm
Frequency 12MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 68
JESD-30 Code S-PQCC-J68
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Supplies 5V
Temperature Grade INDUSTRIAL
Voltage 5V
uPs/uCs/Peripheral ICs Type MICROPROCESSOR
Supply Current-Max 62.5mA
Bit Size 16
Access Time 12 μs
Address Bus Width 20
Boundary Scan NO
Low Power Mode YES
External Data Bus Width 8
Format FIXED POINT
Integrated Cache NO
RAM (words) 0
Number of External Interrupts 5
Number of DMA Channels 2
Dimensions
Height Seated (Max) 4.83mm
Length 24.2316mm
Width 24.2316mm
Compliance
RoHS Status Non-RoHS Compliant
