EP9301-IQZ
RoHS
RoHS compliant
RoHS compliantPackage 208-LQFP
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
IC MPU EP9 166MHZ 208LQFP
PDF
/
Buying Options
Total Price: USD $11.06
Unit Price: USD $11.0599
≥1 USD $11.0599
≥10 USD $9.07535
≥100 USD $8.7913
≥500 USD $8.5082
≥1000 USD $8.22415
Inventory: 1088
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mount Surface Mount
Package / Case 208-LQFP
Number of Pins 208
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Published 2001
Series EP9
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 208
Subcategory Microprocessors
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Frequency 166MHz
Base Part Number EP9301
Operating Supply Voltage 1.8V
Interface Ethernet, I2S, SPI, UART, USB
RAM Size 2B
Memory Type FLASH
uPs/uCs/Peripheral ICs Type MICROPROCESSOR
Core Processor ARM920T
Bit Size 32
Access Time 166 μs
Data Bus Width 16b
Address Bus Width 26
Core Architecture ARM
Boundary Scan YES
Low Power Mode YES
Integrated Cache YES
Voltage - I/O 1.8V 3.3V
Ethernet 1/10/100Mbps (1)
Number of Cores/Bus Width 1 Core 32-Bit
Graphics Acceleration No
RAM Controllers SDRAM
USB USB 2.0 (2)
Additional Interfaces AC'97, I2S, IrDA, SPI, UART
Number of Cores 1
Security Features Hardware ID
Dimensions
Length 28mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
