EP7309-CVZ
RoHS
/
Package 208-LQFP
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
Processors - Application Specialized IC Ultra Low Power Audio Decode SOC
PDF
/
Inventory: 4281
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 28mm
Length 28mm
Height 1.4mm
Technical
Display & Interface Controllers Keypad, LCD, Touchscreen
Security Features Hardware ID
Number of Cores 1
Additional Interfaces DAI, IrDA, SSI, UART
Graphics Acceleration No
Number of Cores/Bus Width 1 Core 32-Bit
Voltage - I/O 2.5V 2.7V 3.0V 3.3V
RAM (words) 48000
Boundary Scan YES
Core Architecture ARM
Data Bus Width 32b
Access Time 74 μs
Core Processor ARM7TDMI
RAM Size 48kB
Number of I/O 27
Interface Serial, UART
Supply Voltage-Max (Vsup) 2.7V
Operating Supply Voltage 2.5V
Pin Count 208
Base Part Number EP7309
Frequency 74MHz
Terminal Pitch 0.5mm
Supply Voltage 2.5V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Number of Terminations 208
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series EP7
Published 2000
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Weight 2.587007g
Number of Pins 208
Surface Mount YES
Package / Case 208-LQFP
