N80C188-25
RoHS
/
Package PLCC
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
PDF
/
Buying Options
Total Price: USD $9.86
Unit Price: USD $9.8648
≥1 USD $9.8648
Inventory: 11663
Minimum: 1
-
+
Technical Details
Physical
Package / Case PLCC
Surface Mount YES
Number of Pins 68
Technical
JESD-609 Code e0
Number of Terminations 68
ECCN Code 3A001.A.3
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Additional Feature DRAM REFRESH CONTROL UNIT; PROGRAMMABLE INTERRUPT CONTROLLER
HTS Code 8542.31.00.01
Subcategory Microprocessors
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 68
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 4.5V
uPs/uCs/Peripheral ICs Type MICROPROCESSOR
Supply Current-Max 125mA
Bit Size 16
Frequency (Max) 25MHz
Data Bus Width 16b
Address Bus Width 20
Boundary Scan NO
Low Power Mode YES
Format FIXED POINT
Integrated Cache NO
RAM (words) 0
Number of External Interrupts 5
Number of DMA Channels 2
Dimensions
Height Seated (Max) 4.572mm
Length 24.2062mm
Compliance
RoHS Status RoHS Compliant
