Z8F082APH020SC
RoHS
/
Package 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB FLASH 20DIP
PDF
/
Inventory: 8570
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Dimensions
Length 25.905mm
Height Seated (Max) 4.49mm
Technical
CPU Family Z8
Core Architecture Z8
ROM (words) 8192
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Access Time 20 μs
Data Converter A/D 7x10b
Bit Size 8
Connectivity IrDA, UART/USART
Program Memory Size 8KB 8K x 8
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, LED, LVD, POR, PWM, Temp Sensor, WDT
Core Processor eZ8
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 2.7V~3.6V
RAM Size 1K x 8
Number of I/O 17
Oscillator Type Internal
Memory Size 8kB
Interface IrDA, UART, USART
Supply Voltage-Min (Vsup) 2.7V
Power Supplies 3/3.3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
Pin Count 20
Base Part Number Z8F082A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 20MHz
Terminal Pitch 2.54mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
HTS Code 8542.31.00.01
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series Encore!? XP?
Published 2006
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 20
Surface Mount NO
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
