Z8F0813HH005EG
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB FLASH 20SSOP
PDF
/
Buying Options
Total Price: USD $3.85
Unit Price: USD $3.848061
≥1 USD $3.848061
≥10 USD $3.630243
≥100 USD $3.424755
≥500 USD $3.230905
≥1000 USD $3.048023
Inventory: 1540
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Number of Pins 20
Technical
Operating Temperature -40°C~105°C TA
Packaging Tube
Published 2005
Series Encore!? XP?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 430mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 3V
Terminal Pitch 0.65mm
Frequency 5MHz
Base Part Number Z8F0813
Pin Count 20
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Interface IrDA, UART, USART
Memory Size 8kB
Oscillator Type Internal
Number of I/O 16
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 2.7V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor eZ8
Peripherals Brown-out Detect/Reset, LED, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 8KB 8K x 8
Connectivity IrDA, UART/USART
Bit Size 8
Watchdog Timer Yes
Access Time 5 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
CPU Family Z8
Dimensions
Height Seated (Max) 1.98mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
