TMP86CM47AUG
RoHS
/
Package LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: 7456
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 10mm
Height Seated (Max) 1.7mm
Technical
RAM (bytes) 1024
Number of Programmable I/O 35
CPU Family TLCS-870/C
Number of Timers/Counters 3
DAC Channels NO
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Frequency (Max) 16MHz
Bit Size 8
Supply Current-Max 9mA
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Memory Type ROM
RAM Size 1kB
Number of I/O 35
Power Dissipation-Max 250mW
Memory Size 32kB
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Interface UART
Temperature Grade INDUSTRIAL
Operating Supply Voltage 5V
Pin Count 44
Terminal Pitch 0.8mm
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Additional Feature OPERATES AT 1.8V MINIMUM SUPPLY AT 4.2 MHZ
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 44
Pbfree Code yes
Physical
Number of Pins 44
Surface Mount YES
Package / Case LQFP
