TMP86C820F
RoHS
/
Package PQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: 2021
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case PQFP
Surface Mount YES
Number of Pins 64
Technical
JESD-609 Code e0
Number of Terminations 64
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature OPERATES AT 1.8 V MINIMUM SUPPLY @ 4.2 MHZ
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 0.8mm
Pin Count 64
Operating Supply Voltage 5V
Temperature Grade INDUSTRIAL
Max Supply Voltage 5.5V
Min Supply Voltage 4.2V
Memory Size 8kB
Power Dissipation-Max 350mW
Number of I/O 39
RAM Size 256B
Memory Type ROM
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Supply Current-Max 9mA
Bit Size 8
Frequency (Max) 16MHz
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
ROM (words) 8192
CPU Family TLCS-870/C
Number of Programmable I/O 39
RAM (bytes) 256
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
