TMS370C756AFNT
RoHS
/
Package 68-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 8-BIT MICRO
PDF
/
Inventory: 2486
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 24.33mm
Length 24.33mm
Height 4.06mm
Technical
Number of SPI Channels 1
Number of ADC Channels 8
Number of Programmable I/O 64
EEPROM Size 512 x 8
Number of Timers/Counters 2
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Access Time 5 μs
Data Converter A/D 8x8b
Bit Size 8
Supply Current-Max 56mA
Connectivity SCI, SPI
Program Memory Size 16KB 16K x 8
Core Size 8-Bit
Program Memory Type OTP
Peripherals PWM, WDT
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
Memory Type EPROM, OTP
RAM Size 512 x 8
Number of I/O 46
Oscillator Type Internal
Memory Size 16kB
Interface SCI, SPI
Power Supplies 5V
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 68
Base Part Number 370C756
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 5MHz
Reach Compliance Code unknown
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form J BEND
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 68
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Discontinued
Pbfree Code no
JESD-609 Code e4
Series TMS370
Packaging Tube
Operating Temperature -40°C~105°C TA
Physical
Number of Pins 68
Package / Case 68-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
